| 1 |
Degree of protection |
IP40 |
| 2 |
UV Resistance |
Button materail UVresistance 94 |
| 3 |
Max. current/voltage rating with resistive load |
5A 125VAC |
| 4 |
Electrical Life Expectancy |
2000,000cycles |
| 5 |
Mechanical Life Expectancy |
10,000,000cycles |
| 6 |
Operating Temperature |
-30 to +50°C |
| 7 |
Initial contact resistance |
30m |
| 8 |
Insulation resistance |
100m min. at500VDC |
| 9 |
Operating Force |
30 to 400gf |
| 10 |
Total Travel |
1.5mm |
| 11 |
Push Button Type |
Momentary |
